Adapters / Connectors

This is an AC Adaptor for the Portable DL350 ScopeCorder available for use in multiple global regions (North America adaptor pictured).

AC Adapter*
* For the countries that require CE marking.

AC Adapter*
* For outside the countries that require CE marking.

Suffix codes Descriptions
-D UL/CSA Standard
-F VDE Standard
-H Chinese Standard
-N Brazilian Standard
-P Korean Standard
-Q BS/Singaporean Standard
-R Australian Standard
-T Taiwanese Standard
-A Argentine Standard
  • 701937,701938, 701939, 701943 (PB500) and 700939

For conversion between BNC and female banana plug
Applicable for DL750/DL750P, SL1000 & SL1400.

- Applicable connector:
12-fiber or 24-fiber (AQ9340-12)
16-fiber or 32-fiber (AQ9340-16)
- Compatible with both with and without guide pins
- Applicable fiber
SM(9.5/125µm)* , GI(50/125µm)
 * AQ9340-12
- Applicable sensor:
AQ2200-232 Optical Sensor Head (Large diameter detector, 800 to 1700 nm),
AQ2200-242 Optical Sensor Head (Large diameter detector, 400 to 1100 nm)

USB communication dedicated cable between PC and the main unit

Packaging:
Infrared communication adaptor and Communications cable (USB) 1 set.
CD contents: Communication driver, User’s manual, Install manual.

  • Yokogawa Oscilloscope and ScopeCorder products
  • A1002JC NDIS connector
  • Direct connection to strain module 701270

For use with 4 mm diameter x 6 mm diameter PVC tubing

For use with 4 mm diameter x 6 mm diameter PVC tubing

Suffix Descriptions
-FC FC type
-SC SC type
  • AQ9447 Connector Adapters
  • For optical input port
  • AQ6370 Series Optical Spectrum Analyzer Accessories

For AQ2170 /AQ2170H /AQ2180 /AQ2180H

For AQ2170 /AQ2170H /AQ2180 /AQ2180H

For AQ2170 /AQ2170H /AQ2180 /AQ2180H

For AQ2170 /AQ2170H /AQ2180 /AQ2180H

For AQ2170 /AQ2170H /AQ2180 /AQ2180H

For AQ4280A /AQ4280B /AQ4280C

For AQ4280A /AQ4280B /AQ4280C

For AQ4280A /AQ4280B /AQ4280C

For 701937,701938, 701939, 701943 (PB500) and 700939 Standard accessories include: Adapter, red wire (3), black wire (3)

- Adapter for a ribbon fiber folder of fusion splicer
- Fiber count: 2, 4, 8 and 12 fibers
- Applicable fiber
SM(9.5/125µm), GI(50/125µm)
- Applicable sensor:
AQ2200-232 Optical Sensor Head (Large diameter detector, 800 to 1700 nm),
AQ2200-242 Optical Sensor Head (Large diameter detector, 400 to 1100 nm)

Connector set for the 91051 (quick adapter, pressure conversion adapter, flexible hose, sealing tape)

Connector set for the 91056 (quick adapter, sealing cap, flexible hose, sealing tape, and hex wrench)

  • 758921 Fork Terminal Adapters
  • For fitting a 4mm banana plug to a fork terminal
  • One black and one red clip
  • 1000 Vrms-CAT II

For 701937, 701938, 701939, 701943 (PB500) and 700939.
Quantity of 1 unit: 10

A clip set designed for 701937, 701938, 701939, 701943 (PB500) and 700939

  • SU2005A-FCC Universal Connector Adapter (FC)
  • for Optical Time Domain Reflectometer unit
  • SU2005A-FCC Universal Adapter (FC)
  • for Optical Time Domain Reflectometer unit

Rated at 300 V. Attaches to the 758917 test leads. Sold in pairs.

  • Yokogawa 758929 Alligator Clip Adapter
  • Rated at 1000V
  • Attaches to 758917 test leads
  • Sold in pairs black/red

2 safety terminal - alligator clip adapters (red and black). Rating 1500 V

Two adapters in a set for current input of the PX8000

Two adapters in a set (spring-hold type).

Screw-fastened adapters. Two adapters in a set. 1.5 mm Allen Wrench.

D-Sub 9-pin connector with 2 screws
(female on connector side)

Screw-fastened type adapters for 30 A element. Black/Red two adapters in a set.

Used in temperature measurement (for CA71).

Used for temperature measurement.

Power supply from measure line(100 to 240 V)

Female-female type adapters for 5 A element. Black/Red two adapters in a set.

Two adapters to a set for 5 A current
(screw-fastened type using B9317WD)

BNC-Banana-jack (female) adapter. Use for circuits having voltage levels no greater than 42 V.

Banana-plug (male)-BNC adapter. Use for circuits having voltage levels no greater than 42 V.

T-adapter for BNC connectors. Use for circuits having voltage levels no greater than 42 V.

Safety-terminal-binding-post adapter. Use for circuits having voltage levels no greater than 42 V.

R 1/4" male thread to 1/8” NPT female thread conversion connector (for -P1)

R 1/4” male thread to 1/4” NPT female thread conversion connector (for -P1)

1/4” NPT male thread to 1/8” NPT female thread conversion connector (for –P2)

1/2” NPT male thread to 1/8” NPT
female thread (for -P4)

1/2” NPT male thread to 1/4” NPT female thread
conversion connector (when -05 is selected)

1/2” NPT male thread to Rc1/4” female thread conversion
connector (when -05 is selected)

1/2” NPT male thread to 1/4” NPT
female thread (for -P4)

1/2” NPT male thread to Rc 1/4”
female thread (for -P4)

By connecting a GI 50 or GI 62.5 optical fiber with a relatively large NA to the NA Conversion Fiber, the NA Conversion Fiber reduces the loss that occurs at the input and improves the measurement dynamic range during passive device measurements and the stability of optical level measurements during active device measurements.

FC connector, for optical sensors
(A light shielding cap is not included)

SC connector, for optical sensors
(A light shielding cap is not included)

LC connector, for optical sensors
(Dust protection cap is not included)

MU connector, for optical sensors
(Dust protection cap is not included)
