An Optical Time Domain Reflectometer (OTDR) is a precision tool used to detect faults and measure loss along fiber optic links by analyzing backscattered light from high-speed pulses. Essential for both installation and maintenance, OTDRs ensure network reliability with accurate fault location, robust field performance, and intuitive operation.
- 6 models in AQ7290 series
- Up to 47 dB dynamic range
- Wavelengths:1310 / 1550 / 1625 / 1650 nm
- 13 module types
- Up to 50 dB dynamic range
- Wavelengths: 1310 / 1383 / 1490 / 1550 / 1625 / 1650 nm
- 6 models in AQ1210 series
- Up to 42 dB dynamic range
- Wavelengths: 1310 / 1383 / 1490 / 1550 / 1625 / 1650 nm
- 12-channel switch for automating fiber selection
- Control directly from an OTDR
- Test all or a subset of channels
- Convenient testing multiple ribbon fibers MPO/MTP
- OTDR for RFTS (Remote Fiber Test System)
- Live network or PON testing with built-in cut filter
- 2 models in AQ7277B Series
- Up to 50 dB dynamic range
- Wavelengths: 1550 / 1650 nm
- Display and analyze OTDR trace data (.SOR)
- Generate work reports
- Intuitive operation enhances efficiency for I&M personnel
Single Mode Optical Fiber
AQ7290
| Model | Number of Wavelength |
High DR | Cut Filter | Number of OTDR port |
Dynamic range (dB) (Typ) | Application | Features | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1310 nm |
1550 nm |
1625 nm |
1650 nm |
Installation | Maintenance | |||||||
| Dark | Live | |||||||||||
| AQ7292A | 2 | 1 | 39 | 37 | ● | ● | Short range model up to 70 km with communication service Wavelength. | |||||
| AQ7293A | 2 | ● | 1 | 43 | 42 | ● | ● | Equipped with communication wavelengths and includes a splitter with no more than 128 branches Standard model ideal for networks. | ||||
| AQ7294A | 2 | ● | 1 | 47 | 47 | ● | ● | High DR model equipped with communication wavelength and suitable for long distance measurement over 100 km. | ||||
| AQ7293F | 3 | ● | ● | 2 | 43 | 42 | 40 | ● | ● | 2-port 3-wavelength model ideal for maintenance of working lines with 1650 nm with built-in optical filter. | ||
| AQ7293H | 3 | ● | 1 | 43 | 42 | 40 | ● | ● | 1-port 3-wavelength standard model with 1625 nm in addition to communication wavelength. | |||
| AQ7294H | 3 | ● | 1 | 47 | 47 | 45 | ● | ● | 1-port 3-wavelength High DR model with 1625 nm in addition to communication wavelength | |||
AQ7280
| Model | Number of wavelength | High DR | Cut Filter | Number of OTDR port | Dynamic range (dB) (Typ) | Application | Fiber Network | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1310 nm | 1383 nm | 1490 nm | 1550 nm | 1625 nm | 1650 nm | Installation | Maintenance | Research ・ Manufacturing |
Core | Metro | Access | PON | ||||||
| Dark | Live | |||||||||||||||||
| AQ7282A | 2 | 1 | 38 | 36 | ● | ● | ● | ● | ||||||||||
| AQ7283A | 2 | ● | 1 | 42 | 40 | ● | ● | ● | ● | ● | ||||||||
| AQ7284A | 2 | ● | 1 | 46 | 45 | ● | ● | ● | ● | ● | ||||||||
| AQ7285A | 2 | ● | 1 | 50 | 50 | ● | ● | ● | ● | ● | ||||||||
| AQ7283E | 3 | ● | ● | 2 | 42 | 40 | 40 | ● | ● | ● | ● | ● | ● | |||||
| AQ7283F | 3 | ● | ● | 2 | 42 | 40 | 40 | ● | ● | ● | ● | ● | ● | |||||
| AQ7282G | 3 | 1 | 38 | 36 | 36 | ● | ● | ● | ● | |||||||||
| AQ7283H | 3 | ● | 1 | 42 | 40 | 39 | ● | ● | ○ | ● | ● | ● | ||||||
| AQ7284H | 3 | ● | 1 | 46 | 45 | 44 | ● | ● | ○ | ● | ● | ● | ||||||
| AQ7283K | 4 | ● | 1 | 42 | 38 | 40 | 40 | ● | ● | ○ | ● | ● | ● | |||||
| AQ7286A | 2 | ● | 1 | 42 | 40 | ● | ||||||||||||
| AQ7286H | 3 | ● | 1 | 42 | 40 | 39 | ● | |||||||||||
| AQ7286J | 4 | ● | 1 | 42 | 39 | 40 | 39 | ● | ||||||||||
○: Using an external filter
AQ1210
| Model | Number of wavelength | High DR | Cut Filter | Number of OTDR port | Dynamic range (dB) (Typ) | Application | Fiber Network | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1310 nm | 1383 nm | 1490 nm | 1550 nm | 1625 nm | 1650 nm | Installation | Maintenance | Core | Metro | Access | PON | ||||||
| Dark | Live | ||||||||||||||||
| AQ1210A | 2 | 1 | 37 | 35 | ● | ● | ● | ● | |||||||||
| AQ1215A | 2 | ● | 1 | 42 | 40 | ● | ● | ● | ● | ● | |||||||
| AQ1210E | 3 | ● | 2 | 37 | 35 | 35 | ● | ● | ● | ● | ● | ||||||
| AQ1215E | 3 | ● | ● | 2 | 42 | 40 | 39 | ● | ● | ● | ● | ● | ● | ||||
| AQ1215F | 3 | ● | ● | 2 | 42 | 40 | 37 | ● | ● | ● | ● | ● | ● | ||||
| AQ1216F | 3 | ● | ● | 2 | 42 | 40 | 40 | ● | ● | ● | ● | ● | ● | ||||
AQ7277B
| Model | Number of wavelength | High DR | Cut Filter | Number of OTDR port | Dynamic range (dB) (Typ) | Application | Fiber Network | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1550 nm | 1650 nm | Installation | Maintenance | Core | Metro | Access | PON | ||||||
| Dark | Live | ||||||||||||
| AQ7277B-B01 | 1 | ● | ● | 1 | 40 | ● | ● | ● | ● | ● | |||
| AQ7277B-B02 | 1 | ● | 1 | 50 | ● | ● | ● | ● | |||||
AQ1000
| Model | Number of wavelength | High DR | Cut Filter | Number of OTDR port | Dynamic range (dB) (Typ) | Application | Fiber Network | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1310 nm | 1383 nm | 1490 nm | 1550 nm | 1625 nm | 1650 nm | Installation | Maintenance | Core | Metro | Access | PON | ||||||
| Dark | Live | ||||||||||||||||
| AQ1000 | 2 | 1 | 32 | 30 | ● | ● | ● | ||||||||||
Operation of the AQ7280 and AQ1210 has been verified in combination with the following third-party products.
For the details of each products, please visit the website of each manufacturer.
Please note that Yokogawa do not guarantee the all operation of the contents posted on each manufacturer's website.
Wired LAN adapter
| Manufacturer | Product name / model number | Supported Products | ||
|---|---|---|---|---|
| AQ7280 | AQ1210 | AQ1000 | ||
| TP-Link | UE300 | － | ● | － |
Wireless SD card
| Manufacturer | Product name / model number | Supported Products | ||
|---|---|---|---|---|
| AQ7280 | AQ1210 | AQ1000 | ||
| KIOXIA | FlashAirTM（32GB or less） | ● | － | － |
※This feature may not be available due to the discontinuation of FlashAir™.
Wireless LAN adapter
| Manufacturer | Product name / model number | Supported Products | ||
|---|---|---|---|---|
| AQ7280 | AQ1210 | AQ1000 | ||
| TP-Link | TL-WN725N | － | ● | － |
| COMFAST | CF-WU810N | － | ● | － |
For AQ1000, to use the wireless feature, Wireless functionality option (/WLN) must be selected at the time of purchase.
Fiber inspection probe
| Manufacturer | Product name / model number | Function | Supported Products | |||
|---|---|---|---|---|---|---|
| Fiber surface image display (standard feature) |
Fiber surface test function (option) |
AQ7280 | AQ1210 | AQ1000 | ||
| Lightel | DI-2000 | ● | ● | ● | ● | － |
| Lightel | DI-1000 | ● | ● | ● | ● | － |
| Lightel | CI-1100 (discontinued) | ● | － | ● | ● | － |
| Eternal | FVO-730B-P | ● | － | ● | ● | － |
Overview of optical communications via optical fibers including: signal conversion, optical fiber benefits, techniques like wavelength division multiplexing (WDM) for increased capacity, key components like optical amplifiers and spectrum analyzers for maintaining transmission quality.
This paper describes a compact optical channel monitor and a delayed interferometer having free-space optical elements such as lenses or mirrors, as an application of microoptics. These devices have been developed to be built into dense wavelength division multiplexing (DWDM) transmission systems. These optics use a Gaussian beam which is emitted through single-mode optical fibers and located near the optical axis. This paper explains the optical designs of these devices based on the Gaussian beam's behavior.
SANPEI Yoshihiro*1 SUZUKI Yasuyuki*2 IEMURA Kouki*3 ASANO Junichirou*3
*1Communication and Measurement Business Headquarters, Optical Communication Measurement Development Department
*2Communication and Measurement Business Headquarters, Core Technology Development Department
*3Photonics Business Headquarters, Engineering Department IV
We are currently aware of this issue occuring on model Optical Time Domain Reflectometer AQ7270's with firmware Ver. 1.02. Please download and install the latest firmware version from the Yokogawa software drivers & firmware website: ...
On the AQ7270 OTDR, there is an Averaging Method function with two measurement modes: High Speed or High Reflection. High SpeedThe high speed mode is used to measure all sections using a fixed attenuation setting. If ...
To delete all user files from the internal memory of the AQ7270 or AQ7275 Optical Time Domain Reflectometer (OTDR), follow the procedures listed below: Power up the AQ720 or AQ7275 OTDR Press the OTDR soft key Press the FILE key Press the ACTION soft ...
Yes, the AQ7275 has a USB 1.1 port that can be used to remotely control the OTDR.
The SU2005A-LCC universal connector is physically compatible with AQ7275, but we do not recommend it because we expect poor connection repeatability and return loss. We cannot guarantee the performance of AQ7275 when ...
The maximum visible light source distance that can be seen by the AQ7275 Optical Time Domain Reflectometer, through a standard SM fiber, is approximately 5 km or 3.1 miles.
The Chopped Light mode is used: To increase measurement level sensitivity by cutting the high frequency noise To detect only the light that the LS emitted, effective for free space measurement. In free space ...
The Cursor value on the AQ7270 Optical Time Domain Reflectometer displays the level in dB that the signal is above the noise floor of the optical port you are connected to. The noise floor is basically the Dynamic range. This lets you know if you are approaching the ...
Yes, the AQ7932 OTDR Emulation Viewer Software is compatible with Windows 7 32-bit and 64-bit. Note: Please make sure the correct USB driver is installed for either Windows 7 32-bit or 64-bit.
Yes, the AQ7270 Optical Time Domain Reflectometer Viewer Software is compatible with Windows 7 32-bit and 64-bit. Note: Please make sure the correct USB driver is installed for either Windows 7 32-bit or 64-bit.
Please download the attached Word document for a list of compatible USB drivers for the AQ7270 and AQ7275 Optical Time Domain Reflectometer Series.
No, unfortunately due to the number of current fiber combinations, we do not stock optical fibers. There are many companies that specialize in optical fiber cords.
The cursor value displays the level (dB) of the signal that is above the noise floor of the connected optical port. The noise floor is the dynamic range. This lets you know if you are approaching the maximum distance ...
