The multi-unit synchronization option for the Yokogawa Test&Measurement DL950 ScopeCorder lets you time synchronize up to five DL950 ScopeCorders, for up to 160 channels of voltage, current, temperature, strain measurements, and more. This video walks you through how to set up and connect the multiple DL950 ScopeCorders, take measurements, and pull the data from all of the instruments for analysis with the IS8000 Integrated Test and Measurement Software Platform.
The multi-unit synchronization option for the Yokogawa Test&Measurement DL950 ScopeCorder lets you time synchronize up to five DL950 ScopeCorders, for up to 160 channels of voltage, current, temperature, strain measurements, and more. This video walks you through how to set up and connect the multiple DL950 ScopeCorders, take measurements, and pull the data from all of the instruments for analysis with the IS8000 Integrated Test and Measurement Software Platform. PLEASE NOTE: The multi-unit sync feature requires the latest versions of the DL950 ScopeCorder firmware and the IS8000 Integrated Test and Measurement Software Platform to operate effectively. Be sure you have the latest updates before proceeding to use the feature. DL950 ScopeCorder: https://bit.ly/3wIhFlk DL950 ScopeCorder Firmware: https://bit.ly/39LxMXw IS8000 Integrated Test and Measurement Software Platform: https://bit.ly/3GeHj5l "How to Time Synchronize 160 Input Channels with Multi-Unit Synchronization using a Yokogawa Test&Measurement DL950 ScopeCorder" ________________________________________________________________________ Connect with Yokogawa Test&Measurement on LinkedIn: https://www.linkedin.com/showcase/yokogawa-test&measurement Meet the Precision Makers at https://tmi.yokogawa.com/ Yokogawa has been developing measurement solutions for 100 years, consistently finding new ways to give R&D teams the tools they need to gain the best insights from their measurement strategies. The company has pioneered accurate power measurement throughout its history and is the market leader in digital power analyzers. Yokogawa instruments are renowned for maintaining high levels of precision and for continuing to deliver value for far longer than the typical shelf life of such equipment. Yokogawa believes that precise and effective measurement lies at the heart of successful innovation - and has focused its own R&D on providing the tools that researchers and engineers need to address challenges great and small. ________________________________________________________________________ Chapters: 00:00 Introduction 00:28 Multi-unit sync explanation 01:06 What you need for setup 01:23 Physically connecting the units 02:22 Setting the DL950s for synchronization 02:44 Changing the settings on the DL950s 03:05 Saving files 03:49 DAQ mode in IS8000 04:37 Opening saved files in IS8000 05:51 Conclusion
