Digitale Leistungsanalysatoren
Yokogawa ist weltweit führender Hersteller von hochgenauen, digitalen Leistungsmessinstrumenten. Die Leistungsmesstechnik von Yokogawa zeichnet sich durch höchste Präzision, Stabilität und Zuverlässigkeit aus. Konservative Spezifikation und ein solider Aufbau garantieren einen langlebigen Einsatz der Geräte, welcher weit über den vergleichbarer Messinstrumente hinausgeht. Das Produktspektrum startet bei einem tragbaren Netzqualitätsanalysator und endet bei Referenzgeräten der höchsten Genauigkeitsklasse.
-
Der Präzisions-Leistungsanalysator WT5000 definiert die neue Referenz in der Leistungsmesstechnik mit einer aktuell weltweit höchsten Grundgenauigkeit von ± (0,01 % des Messwerts + 0,02 % des Effektivwert-Messbereichs). Jedes erdenkliche Anwenderszenario wird durch die modulare Bauweise (Self-Service) sowie durch die mögliche Kaskadierung realisiert: bis zu 28 Leistungsmesskanäle plus 16 Motoreingänge gewährleisten vollumfängliche Messungen. Die neue „Digital Parallelpfad-Technologie“, wie auch die Harmonischen-Analyse (bis zur 500. Ordnung) runden den Leistungsumfang ab.
-
Der Präzisions-Leistungsanalysator WT3000E zeichnet sich durch eine sehr hohe Leistungsmessgenauigkeit von ± (0,01 % des Messwerts + 0,03 % des Effektivwert-Messbereichs) bei Grundfrequenzen aus. Mit bis zu vier Leistungsmesskanälen und einem Eingang für Drehmoment und Drehzahl können Wirkungsgrade bestimmt werden. Perfekt bietet sich der WT3000E auch für Harmonischen-Analysen, Flicker-Analysen und Standby-Messungen nach neuesten IEC sowie EN Normen an.
-
Der WT1800E ist ein flexibler und zuverlässiger Leistungsanalysator, der eine Leistungsmessgenauigkeit von ±(0,05 % des Messwerts + 0,05 % des Effektivwert-Messbereichs) gewährleistet. Er kann Oberschwingungen bis zur 500. Ordnung der 50/60-Hz-Grundfrequenz analysieren. Mit bis zu 6 Eingangskanälen, vielfältigen Anzeige- und Analyse-Funktionen sowie PC-Schnittstellen ist der WT1800E ideal für unterschiedlichste Anforderungen aus den Bereichen Energieeffizienz und Analyse von Oberschwingungen geeignet.
-
Kompakt und einfach einzusetzen. Der Leistungsanalysator für Anwendungen rund um die Erzeugung erneuerbarer Energien. Strombereich: 0,5 bis 40 A, Spannungsbereich: 15 bis 1000 V, Grundgenauigkeit: 0,2 %, Frequenzbereich: DC bis 100 kHz. Standardmäßig mit Stern/Dreieck Umrechnung und simultaner Oberschwingungsanalyse.
-
Die kompakten Leistungsmessgeräte der Serie WT300E zeichnen sich durch eine Grundgenauigkeit von ±(0,1 % des Messwerts + 0,05 % des Effektivwert-Messbereichs) aus und sind ideal für die Messung des Stromverbrauchs von elektrischen Geräten sowie für Untersuchungen in den Bereichen Energieeffizienz und Energieeinsparung geeignet.
-
Yokogawa hat beim PX8000 seine langjährigen Erfahrungen aus den Bereichen der Leistungsmessgeräte und Oszilloskope gebündelt und eine revolutionäre Test- und Messlösung entwickelt: das weltweit erste Precision Power Scope – ideal für die transiente Leistungsmessung.
-
Der CW500 von Yokogawa ist ein tragbares Leistungsmessgerät, das mittels Stromzangen, Navigationsmenüs und Schnellstart-Guides benutzerfreundlich Messungen zum Stromverbrauch und zur Netzqualität im Feld gemäß dem Standard IEC 6100-4-30 Klasse S durchführen kann.
-
Die Leistungsmesstechnik von Yokogawa zeichnet sich durch höchste Präzision und Stabilität und beste Leistung im Hinblick auf Genauigkeit, Lesbarkeit, simultane Messfunktionen, fortschrittliche Berechnungen sowie Oberwellen- und Flicker-Messungen aus.
-
Das Zubehör für digitale Leistungsanalysatoren beinhaltet: Stromzangen, Stromsensoren und Stromwandler für die Messung großer Ströme.
| Modell | WT5000 | WT3000E | WT1800E | WT500 | WT300E | PX8000 |
|---|---|---|---|---|---|---|
 |
 |
 |
 |
 |
 |
|
| Anzahl der Eingangskanäle (je Strom/Spannung) |
1 bis 7, skaliert bis 28 |
1 bis 4, skaliert bis 16 |
1 bis 6, skaliert bis 24 |
1 bis 3 | 1 bis 3 | 1 bis 4, skaliert bis 20 |
| Drehzahl- & Drehmomenteingang | JA (4), skaliert bis 16 |
JA (1), skaliert bis 4 |
JA (1), skaliert bis 4 |
NEIN | NEIN | JA (AUX Eingangsmodul) |
| Grundgenauigkeit bei Leistungsmessungen (60 Hz) |
Leistung: 0,01 % des Messwerts + 0,02 % des Bereichs |
Leistung: 0,01 % des Messwerts + 0,03 % des Bereichs |
Leistung: 0,05 % des Messwerts + 0,05 % des Bereichs |
Leistung: 0,1 % des Messwerts + 0,1 % des Bereichs |
Leistung: 0,1 % des Messwerts + 0,05 % des Bereichs |
Leistung: 0,1 % des Messwerts + 0,1 % des Bereichs |
| Frequenzbereich für Leistungsmessungen |
DC 0,1 Hz bis 1 MHz |
DC 0,1 Hz bis 1 MHz |
DC 0,1 Hz bis 1 MHz |
DC 0,5 Hz bis 100 kHz |
DC 0,1 Hz bis 100 kHz |
DC bis 1 MHz |
| A/D-Wandler | 18 Bit 10 MS/s |
16 Bit 200 kS/s |
16 Bit 2 MS/s |
16 Bit 100 kS/s |
16 Bit 100 kS/s |
12 Bit 100 MS/s |
| Effektivwert-Spannungsbereiche | 1,5 V - 1000 V | 15 V - 1000 V | 1,5 V - 1000 V | 15 V - 1000 V | 15 V - 600 V | 1,5 V - 1000 V |
| Effektivwert-Strombereiche | (5 A Element): 5 mA - 5 A; (30 A Element): 0,5 A - 30 A beide Elemente können kombiniert werden |
(2 A Element): 5 mA - 2 A; (30 A Element): 0,5 A - 30 A beide Elemente können kombiniert werden |
(5 A Element): 10 mA - 5 A; (50 A Element): 1 A - 50 A beide Elemente können kombiniert werden |
0,5 A - 40 A | (WT310E): 5 mA - 20 A (WT310EH): 1 A - 40 A (WT330E): 0,5 A - 20 A |
10 mA bis 5 A |
| Harmonischen Analyse (Grundschwingung) |
0,1 Hz - 300.000 Hz max. 500 Harmonische |
10 Hz - 2.600 Hz max. 100 Harmonische |
0,5 Hz - 2.600 Hz max. 500 Harmonische |
10 Hz - 1.200 Hz max. 50 Harmonische |
10 Hz - 1.200 Hz max. 50 Harmonische |
20 Hz - 409.600 Hz max. 500 Harmonische |
| unabhängige Bereichseinstellung | JA | JA | JA | JA | NEIN | JA |
| Display-Typ | 10,1" TFT LCD Touchscreen | 8,4" TFT-Farb-LCD | 8,4" TFT-XGA-Farb-LCD | 5,7" TFT-Farb-LCD | 4 x 7-Segment-LED-Anzeigen | 10,4" TFT-Farb-LCD |
| Speicher | USB-Speicherstick; 2 GB intern; Optional 32 GB intern |
PC Card; USB- Speicherstick; 30 MB intern | USB-Speicherstick; 32 MB intern | USB- Speicherstick; 20 MB intern | Speicher für maximal 600 Messwerte (nur interne Nutzung) |
16 GB SD- und SDHC-Karte, USB-Speicherstick |
| Kommunikations- Schnittstellen |
Standard: GP-IB, Gigabit-Ethernet (1000Base-T), USB 3.0 | Standard: GP-IB, Optional: RS-232, Ethernet, USB | Standard: GP-IB, USB, Ethernet | Standard: USB Optional: GP-IB, Ethernet |
Standard: USB, RS-232 oder GP-IB Optional: Ethernet |
Standard: GP-IB, USB, Ethernet |
| Garantie | 3 Jahre Standard | |||||
TOP-Merkmale des Precision Power Scopes PX8000
